Gigabyte GA-P55-UD6 Mainboard BIOS Screen shots 2
Bluetooth 30 Aug 2009

BIOS 2

The screen shots are taken with board installed with a Core i5 750.

If you use XMP capable modules, you can choose the XMP profile #1 or #2. In this case, our Kingston HyperX module ahs XMP profile for DDR3-2000. It is set to run at C 9 9 9 27 1T	Alternatively, you can choose the system memory multiplier to run the memory in async to BCLK
For users who are sick of adjusting parameters to achieve higher speed. Gigabyte has C.I.A.2 which has 5 modes for you to accelerate your system.	Here is the set up screen of memory timings
Here is a detail Channel A timing settings which you can adjust manually when necessary.
