Jetway I35P-SG Intel P35/ICH9 Mainboard Review Intro 1/6
Bluetooth 8 Oct 2007

Pricing of
P35 boards

>>>

Introduction

Jetway is a 2nd tier mainboard manufacturer from Taiwan. Although Jetway mainboards is seldom seen in some parts of the market, it remains one of the top OEM manufacturers for mainboards and graphics cards. Many of the Hong Kong sticker brand boards actually uses Jetway boards in disguise. They do share similar design and use the same BIOS.

Today, our focus is on Jetway's I35P-SG mainboard based on Intel P35 chipset. Jetway I35P-SG is based on the Intel P35 Express Chipset +Intel ICH9 Chipset. It runs the Intel Intel LGA775 Core Processor Family up to FSB 1333MHz. Memory wise, it supports Dual Channel DDR2 800 / 667 Memory DIMMs.

The board supports a dual PCIex16 slot (4+16 electrically) for CrossFire. It also supports 6 Serial ATA2 Devices with RAID 0,1 function using ICH9 and Jmicron JMB363 (2 SATAII + 1 IDE). The south bridge also supports 12 USB2.0 Connectors. The board also comes with GbE, 8 HDA, eSATA

Just like most overclocking boards from Jetway, this board comes with CPU Vcore 7-Shift. It also has voltage adjustments for VDIMM, VCore, NB, SB, FSB voltages.
