abit IP35 Pro Intel P35/ICH9R Mainboard Review Intro 1/6
Bluetooth 2 Aug 2007

 Pricing of
abit IP35 Pro

>>>

Introduction

Universal abit has been pretty quiet since the early of this year. This is probably due to restructuring and this resulted in very little exposure of their products on the online media. Today, we take a look at one of their latest products, the IP35 Pro.

The fanless heatpipe IP35 Pro is a high end board from Universal abit. It is based on the Intel P35/ICH9R pair and supports the Intel® Core™ 2 Extreme/Duo/Quad processors with 1333/1066/800MHz FSB  and Intel® Core™ 2 Extreme/Quad/Duo & Pentium® Dual Core Processors. It has 4 X 240-pin DIMM sockets support max. memory capacity 8GB of Dual channel DDR2 800/667 Un-buffered Non-ECC memory. The board also comes with Dual Gigabit LAN controller supports 10/100/1000M Ethernet and On board 7.1 CH HD Audio CODEC which supports auto jack sensing and optical S/PDIF In/Out + HDMI ready header (SPDIF header).

The board also comes with Dual full length PCIe slots which allows two graphisc cards to be used on board in CrossFire mode. There are also 6 SATA II ports which supports RAID 0/1/5/10, 2 eSATA by Jmicron MB363, 2 x IEEE 1394, 10 USB ports. -E X16 (x4 bandwidth), 1 x PCI-E X1,

Most importantly, this board has on board power on/off, reset button, that makes and debug led. this makes troubleshooeting easier. Something I like is the EZ for CCMOS. You can now clear the CMOS without opening the casing.

Other features include abit µGuru, OC Guru - AutoDrive™, One Click BIOS Update, Auto-Detect Hardware Info, abit SoftMenu™, CPU ThermalGuard™and abit's Silent OTES™  heatpipe technology




Specs
CPU
  • Support Intel® Core™ 2 Extreme/Duo/Quad processors with 1333/1066/800MHz FSB
  • Support Intel® Core™ 2 Extreme/Quad/Duo & Pentium® Dual Core Processors
    • Chipset
  • Intel® P35 Express / ICH9R Chipset
    • Memory
  • 4 X 240-pin DIMM sockets support max. memory capacity 8GB
  • Supports Dual channel DDR2 800/667 Un-buffered Non-ECC memory
    • LAN
  • On board Dual Gigabit LAN controller supports 10/100/1000M Ethernet
    • Audio
  • On board 7.1 CH HD Audio CODEC
  • Supports auto jack sensing and optical S/PDIF In/Out
  • HDMI ready header (SPDIF header)
    • Expansion Slots
  • 1 x PCI-E X16, 1 x PCI-E X16 (x4 bandwidth), 1 x PCI-E X1, 3 x PCI
    • Internal I/O
  • 1 x Floppy Port supports up to 2.88 MB
  • 1 x ATA 133/100/66/3 IDE connector
  • 6 x SATA 3Gb/s connector
  • 2 x IEEE1394, 3 x USB header (support 6 ports)
  • 1 x FP-Audio
    • Back Panel I/O
  • 1 x PS/2 Keyboard, 1 x PS/2 Mouse
  • abit Silent OTES™
  • 1 x S/P DIF In, 1 x S/P DIF Out
  • 2 x eSATA
  • 7.1 CH Audio connector (Front, Line-in, MIC-in, Center/Subwoofer, Surround, Rear Surround)
  • 4 x USB 2.0
  • 1 x RJ-45 LAN connector
  • EZ CCMOS Switch
    • Serial ATA
  • 6 x SATA 3Gb/s offer by Intel® ICH9R support Intel® Matrix Storage Tech(AHCI & RAID0/1/5/10)
  • 2 x eSATA 3Gb/s through JMicron® JMB363 support 0,1JBOD RAID function
    • IEEE 1394
  • Supports 2 Ports IEEE 1394 at 400Mb/s transfer rate.
    • Form Factor
  • ATX form factor 305 x 245mm
  • PCB Color: Blue
    • RoHS
  • 100% lead-free process and RoHS compliant
    • abit Engineered
  • abit µGuru™ Technology
  • abit Silent OTES™ Technology
  • 100% Japanese made Low ESR and high ripple conductive polymer aluminum solid state capacitor
  • 100% Japanese Capacitor
  • EZ for CCMOS
    • abit Engineered
    abit Engineered abit µGuru
    With abit's unique µGuru technology now even the most novice users can fully monitor and control their system including voltages, fans and temperatures; it's all just a click away. The more advanced you become, the more you will appreciate the multitude of fine tuning features abit's µGuru technology holds for you.
    abit Engineered OC Guru - AutoDrive™
    By enabling AutoDrive, you can automatically apply different overclocking settings for different applications.
    abit Engineered Hardware Monitoring
    Monitor temperatures, voltages and fan settings in real time and with zero CPU usage.

    abit Engineered Dedicated fan control
    Keep control over your hardware. abit Fan EQ™ helps you keep an eye on your motherboard fans.
    abit Engineered One Click BIOS Update
    With abit's BIOS flash utility you can easily update your motherboard BIOS online or offline.
    abit Engineered Auto-Detect Hardware Info
    The abit BlackBox auto-detects hardware info for quick communication between users and abit Tech support.
    abit Engineered abit SoftMenu™
    The original jumperless motherboard design allows for CPU setting changes completely through the BIOS. For GigaOverclocking! Boost your PC's Performance by up to 50%. Convenient and easy-to-use fine tuning from within a self-explanatory BIOS menu.
    abit Engineered abit CPU ThermalGuard™
    The abit CPU ThermalGuard™ technology prevents the CPU from overheating and burning up in the case of any hardware cooling malfunction. This hardware thermal protection automatically shuts down your system when the CPU temperature reaches a certain threshold.
    abit Engineered abit Silent OTES™abit-Engineered
    abit's Silent OTES™  heatpipe technology dissipates heat from the chipset and conducts it to a highly effective heatsink. This fanless solution keeps your motherboard cool and quiet.




    Discuss in Forum

    Next >>>
