Benchmarks

Futuremark 3DMark2005 (1024x768x32)

The card is ran at default clock which is at 594MHz/495MHz (core/mem). A score of 2584 is obtained when a single card is ran on the ECS KA1 MVP Extreme board (ATi RD480 chipset). The board runs with Corsair memory at CAS 2, 6-2-2, 1T cmd.

In terms of overclocking, we managed to push the Core clk to 655 and memory clk at 540. Using the new setting, we were able to obtain a score of 3431.

We got hold of another piece of X1300Pro Bravo and setup the ATI Control Centre to run in CrossFire mode. A score of 5262 is obtained running at default clk. The jump in performance is quite substantial compared to the 3Dmark03.

The results shows that at OC speed, the single card actually outperforms a 6600GT which scores around 3300 on the average. When the two cards combine in CrossFire, the score is amazingly high that is just 800 points less than a Dual 6600GT SLI setup.
