ASrock 939SLI-eSATA2 (ULi M1697) Intro 1/5
Bluetooth 8 Feb 2006
ASrock
939SLI-eSATA2
Right after the sale of the
775XFire-eSATA2 board which supports the
dual graphics technology, ASrock releases yet another surprise for all its users
- ASrock 939SLI-eSATA2. ASrock 939SLI-eSATA2 is the first board manufactured
that supports the ULi M1697 single K8 chipset mainboard that comes with SLI and
eSATA2 support. The board comes with 2 PCIex16 slots which can be configured to
work in a single PCIe x16 mode or Dual PCIe x8. This allows SLI operation by
pairing up two similar GeForce 6600, 6800 or 7800 cards and run it in tandem to
improve graphics performance.
On top of all this, the 939SLI-eSATA2 also supports eSATA2
ports. This allows you to hook up eSATA2 enclosures which allows SATA HDD to be
connected externally without compromising the speed in contrast to the lower
performing USB or 1394 interfaces. The board also features the Future CPU port
which allows one to upgrade to the new AM2 940 pin processor in the near future.
The mainboard comes with 4 ports of Serial ATA II 3.0Gb/s,
RAID 0, 1, 0+1, JBOD and RAID 5, and "Hot Plug" functions, and 2 ATA 133 IDE
ports, 2 ports of eSATAII 3.0Gb/s (shared with 2 SATAII ports), support "Hot
Plug" function. 5.1 Channel with High Definition Audio, 10/100 Ethernet LAN is
supported. The board is also Windows Vista Hardware Ready ROHS compliant.
Specifications
| CPU |
- 939-Pin Socket Supporting AMD Athlon™
64 / 64FX / 64X2 Processor
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied-Overclocking Technology
- Supports Hyper-Transport Technology |
| Chipset |
- ULi M1697 |
| Hybrid Booster |
- CPU
Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.) |
| Memory |
- Dual Channel DDR memory technology
- 4 x DDR DIMM slots
- Supports DDR400/333/266
- Max. capacity: 4GB |
| Expansion Slot |
- 1 x
Future CPU Port (Supports CPU upgrade from AMD K8 939-Pin CPU to AM2 940-Pin
CPU through AM2 CPU Board)
- 3 x PCI slots
- 1 x PCI Express x 16 / x 8 slot
- 1 x PCI Express x 1 x 8 slot
- 1 x PCI Express x 1 slot
- Supports NVIDIA SLI™ |
| Graphics |
- n/a |
| Audio |
- Realtek
ALC 660 5.1 channel CODEC with High Definition Audio |
| LAN |
- Realtek PHY RTL8201CL
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN |
| Connector |
- 4 x
Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1,
JBOD, and RAID 5) and "Hot Plug" functions
- 2 x eSATAII 3.0 Gb/s connectors (shared with 2 SATAII ports), support "Hot
Plug" function
- 2 x ATA133 IDE connectors (support 4 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Game header
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- 4 pin 12V power connector
- SLI/XFire power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports) |
| Rear Panel I/O |
ASRock
eSATAII I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x COM Port
- 1 x Parallel Port (ECP/EPP Support)
- 4 x Ready-to-Use USB 2.0 Ports
- 2 x eSATAII Ports
- 1 x RJ-45 LAN Port
- Audio Jack: Line in / Line out / Microphone |
| BIOS Feature |
- 2Mb AMI
BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support |
| Support CD |
-
Drivers, Utilities, AntiVirus Software (Trial Version) |
| Accessories |
- Quick
Installation Guide, Support CD, I/O shield
- Floppy/ATA 133 cables
- 4 x SATA data cables
- 2 x SATA 1-to-1 power cables |
| Form Factor |
- ATX
Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
| OS |
-
Microsoft Windows 2000/XP/XP 64-bit compliant |
|
Certifications |
- FCC, CE, WHQL |
| |
