3Dmark05 and 3Dmark06 benchmark ASRock 4Core1333-FullHD ATi RS600/SB600 Mainboard Review
Bluetooth 9 Jul 2007

Pricing of
ASRock ConRoe1333-DVI/H

>>>

Benchmarks - 3Dmark2005/3DMark2006

The various boards were tested for its 3Dmark05 and 3Dmark06 3D capability first and then paired up with an external 7900GT card to see how well it performs.

For its integrated graphics, the core clk runs at 500MHz with ram at 400MHz.

In 3Dmark05, the ASRock 4Core1333-FullHD scored 1770. ConRoe1333-D667 scored 852 with Conroe1333DVI/H and ConRoe945G-DVI also scored 851. The Gigabyte board scored 848. The Jetway, based on G965 scored 1061. Apparently, the ASRock 4Core1333-FullHD integrated 3D performance far exceeds that of the 945G, G965.

With an external ASUS EN7900GT TOP card + 91.31 driver, the board scored 9297. That is slightly lower than the rest of the boards. It could be largely due to the lower default clk speed on the bios.

When it comes to 3DMark06, integrated graphics on the ConRoe1333-D667 scored 287, simialr to the ConRoe1333-DVI/H. This score is higher than 273 on the ConRoe945G-DVI. The Jetway G965 scored 585 while the Gigabyte scored 270.

When paired up with an external graphics card ASUS EN7900GT, we can see that the scores of each board are very close to one another.
