Jetway 775GT2-LOG NF 570 SLI Conroe Mainboard 1/5
Bluetooth 14 Aug 2006

 Pricing of
7800GTX

>>>

Introduction

Jetway 775GT2-LOG is the first NV based board that we got hold of that supports the new Core2 Duo / Extreme CPU. This board is based on thenew chipset NF 570 SLI Intel edition + MCP 430 south bridge.

775GT2-LOG supports the P4, Celeron D, Pentium D and Core 2 Duo 775 LGA package 533/800/1066 processors.

It comes with 2 DDR2 DIMM slots supporting up to a maximum of 4GB of memory. In terms of expansion slots, the board comes with three PCIe x16 length slots which will function as 2 x PCIex 8 (Dual green slots) or 1 x PCIe x16 (single yellow slot), depending on where you slot the graphics card. This saves you the trouble of swapping in / out of a peddle card in old designs to switch between SLI and NON SLI mode.

There is 2 PCI slot and 1 PCIe x1 for future expansion. Te board also has 2 PCIe IDE controller supporting ATA133 and 4 SATA ports supporting 3Gb/s and canbe configured to run in RAID 0,1,0+1.

The board comes with 4 USB on board + 4 more through extensions. It also has a Marvell 8*E1116 PCie GbE LAN , 8 Ch audio and SPDIF In/out at the back panel of the mainboard.


Specifications



  • NVIDIA nForce 570 SLI Intel Edition + nForce 430 MCP.

  • Support Inter LGA775 Conroe Processor & Celeron D Processor .

  • Support FSB 1066MHz.

  • Support NVIDIA SLI Technology 8-LANE + 8-LANE .

  • Dual Channel DDR2 667/533 Memory DIMMs.

  • 3 PCI-Express x16 Slots Design.

  • Support 4 Serial ATA2 Devices with RAID.

  • 8 USB2.0 Connectors Embedded.

  • ATX FormFactor.



     LGA775 Intel Core 2 Duo E Series 65nm Processor with Shared 4MB L2 Cache SupportedInnovative design which meets the world,s most advanced 65 nanometer Chip-Making Process technology based Intel?Core 2 Duo E6700, E6600, E6400, E6300, E4200 and beyond Processors with and embedded 4MB / 2MB L2 Cache for demanding usage of Home Networking and Game Enthusiasts.



    NVIDIA nForce 570 SLI Intel Edition and nForce 430 MCP Chipset

    NVIDIA?nForce 570 SLI Intel Edition which offers blistering graphics performance and overall PC performance for both AMD and Intel platforms.  With the power of SLI technology you get the ability to connect two NVIDIA SLI-Ready PCI Express graphics cards for mind-blowing gameplay with brilliant and intensive 3D graphics. The unique low-latency architecture of the NVIDIA nForce 570 SLI that offers one of the industry,s best core-logic solution with outstanding performance and the latest technologies-SLI, PCI Express, secure high-speed networking, and high-performance storage-and ensures that your PC stays ready for the newest games, future applications, and next-generation PC specifications.



    CPU Thermal Throttling / The Anti-superheated CPU protection Technology

    To prevent the increasing heat from damaging of CPU while the activation of the Bi-turbo technology, the CPU Thermal Throttling Technology will make CPU be idling from 87.5% to 12.5% by manually preset CPU operating temperature from 40oC to 90oC. When the system senses the climbing operating temperature of CPU over the value preset, CPU Thermal Throttling Technology will narrow the operating bandwidth of CPU actively to low down the temperature to the value preset as the perfect protection system of hardware dynamic over-clocking technology.



    CPU Smart Fan / The Noise Restrained System

    It is never been a good idea to sacrifice the sound effects for gaining the performance you need. CPU Smart Fan Noise Restrained System is the answer to all the noise restrained needed high performance computing system, the system will automatically increase the fan speed when CPU operating loading is high, after the CPU is in normal operating condition, the system will low down the fan speed for the silent operating environment. The system can provide the much longer life cycle for both CPU and the system fans for game use and business requirements.



    OC-CON high-polymer solid electrolysis aluminum capacitors embedded

    The working temperature is from 55 degrees Centigrade below zero to 125 degrees Centigrade, OC_CON capacitors possess superior physical characteristics that can be while reducing the working temperature between 20 degrees Centigrade each time, intact extension 10 times of effective product  operation lives, at not rising degrees Centigrade of working temperatures each time a relative one, life of product decline 10% only too.



    CPU Vcore Shift / Shift_to the scalabilities and flexibilities

    The adjustable voltage for CPU Vcore can be upgraded over 13 stages for the precisely hardware dynamic over-clocking of demanding computing performance.

    •



    Next >>>
