CPU FSB can be set to 200 ~ 400MHz |
ASync DRAM Clk can be set to run in Sync
to CPUCLK or at Async DDR333, DDR266 or DDR200. |
 |
 |
|
CPU Multiplier allows you to set anything
from x4 to x25. |
CPU Voltage is adjustable from 1.10v to
1.55v. |
 |
 |
|
Needs more voltage, you can adjust up to
+350mV of the CPU Voltage |
DDR voltage. Up to 3.25V is selectable
from the options available. |
 |
 |
|
Needs more stability for overclocking, NB
Voltage might come useful. Up to 1.7v is selectable. |
LDT voltage can be adjusted to 1.25v or
1.35v. |
