Shuttle AS45GTR SiS648 Mainboard Review (3)
Overclocker 15 Jul 2002

Benchmarking

Memory Benchmarks

SiSoft Sandra 2002

The infamous SiSoft Sandra 2002 is used to test out the memory benchmarks. All the systems are tweak to it's maximum possible settings of CAS 2, 2-2-5. The RAMBUS boards are not that customisable and we leave it at the maximum possible running at 4x for CPU/Memory frequency ratio. FSB : 133Mhz.

The chart below compares the memory benchmark scores when we run the board at various CPU/Memory Freq Ratio at DDR266, DDR333 and DDR400. For DDR266 and DDR333, RAM is set to CAS 2, 2-2-5. At DDR400, it is set to CAS 2, 3-3-6. *The BIOS we used in this test is an early BIOS which seems to have it's Async DDR400 timings too aggressively tuned. We skipped the unofficial of DDR400 test.

Comparing to the SiS645DX DDR333 mode, we can see an improvement in the memory performance results. 2567 vs 2488.

Next
